IPC-HFW2431S-S2

4MP WDR IR Bullet Network Camera
·4MP, 1/3” CMOS image sensor, low illuminance, high image definition
·Outputs 4MP (2560 × 1440)@25/30fps, Max. supports 4MP (2688 × 1520)@20 fps
·H.265 codec, high compression ration, ultra-low bit rate
·Built-in IR LED, max IR distance: 30 m
·ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
·Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
·Intelligent detection: Intrusion, tripwire
·Supports max. 256 GB Micro SD card
·12V DC/PoE power support
·IP67 protection grade
Harga :
815,000
Tanya Produk Via Whatsapp

On Share :

Spesifikasi

Camera
Image Sensor
1/3” 4Megapixel progressive CMOS
Effective Pixels
2688 (H) × 1520 (V)
ROM
128MB
RAM
128MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
Minimum Illumination
0.008 Lux@F1.6
IR Distance
30 m (98.43 ft)
IR On/Off Control
Auto / Manual
IR LEDs Number
1
Pan/Tilt/Rotation Range
Horizontal: 0°–360° Vertical: 0°–90° Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
2.8 mm
3.6 mm
Max Aperture
F1.6 F1.6
Field of View
2.8 mm: Pan: 102.0° Tilt: 55.0° Diagonal: 121.0°
3.6 mm : Pan: 84.0° Tilt: 45.0° Diagonal: 100.0°
Iris Type
Fixed aperture
Close Focus Distance
2.8 mm: 0.9 m (2.95 ft) 3.6 mm: 1.6 m (3.61 ft)
Smart Event
General IVS Analytics
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG
Smart Code
Yes
Video Frame Rate
Main stream: 2688 × 1520 (1 fps-20 fps) 2560 × 1440 (1 fps-25/30 fps)
Sub stream: 704 × 576 (1 fps-25 fps) 704 × 480 (1 fps-30 fps)
Streaming Capability
2 streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296);
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 Kbps–6144 Kbps H.265: 12 Kbps–6144 Kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto / Manual
Noise Reduction
3D DNR
Motion Detection
Off / On (4 Areas, Rectangle)
Region of Interest
Yes (4 areas)
Smart IR
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 1080p resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Network
Network
RJ-45 (10/100 Base-T)
Protocol
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP;FTP; SFTP;
DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour
Interoperability
ONVIF(Profile S/Profile G/Profile T);CGI; P2P; Milestone; Genetec
User/Host
20
Edge Storage
Dahua Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
Browser
IE, Chrome, Firefox, Safari
Management Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certification
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
<5 W
Environment
Operating Conditions
-40°C to +60°C (-40°F to +140°F)/less than ≤ 95% RH
