IPC-HFW1431S1

4MP Entry IR Fixed-focal Eyeball Netwok Camera
·4MP, 1/3” CMOS image sensor, low illuminance, high image definition
·Outputs 4MP (2560 × 1440) @25/30 fps, and supports max. 4MP (2688 × 1520) @20 fps
·H.265 codec, high compression rate, ultra-low bit rate
·Built-in IR LED, max. IR distance: 30 m
·ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
·Image flip, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
·Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access, voltage detection
·12V DC/PoE power support
·IP67, protection
Harga :
580,000
Tanya Produk Via Whatsapp

On Share :

Spesifikasi

Camera
Image Sensor
1/3.7" 4Megapixel Progressive CMOS
Effective Pixels
2688(H)×1520(V)
ROM
128
RAM
128
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Min. Illumination
0.03 Lux @ F2.0(IR on)
IR Distance
Distance up to 30m(98.4ft)
IR On/Off Control
Auto/Manual
IR LEDs
1

Pan/Tilt Range
Horizontal: 0°–360°
Vertical: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Fixed
Mount Type
M12
Focal Length
2.8mm3.6mm
Max Aperture
F2.0
Field of View
2.8 mm:
Horizontal: 93°; Vertical: 53°; Diagonal: 111°
3.6 mm:
Horizontal: 81°; Vertical: 44°; Diagonal: 95°
Iris Type
Fixed aperture
Close Focus Distance
2.8 mm: 0.8 m (2.6 ft)
3.6 mm: 1.4 m (4.6 ft)
Video
Video Compression
H.265; H.264; H.264B; MJPEG
Smart Codec
Yes
Video Frame Rate
Main Stream:
2688 × 1520 (1 fps–20 fps)2560 × 1440 (1 fps–25/30 fps)
Sub Stream:
704 × 576 (1 fps–20/25 fps)704 × 480 (1 fps–20/30 fps)
Stream Capability
2 streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440);
2304 × 1296 (2304 × 1296);1080p (1920 × 1080); 1.3M(1280 × 960); 720p (1280 × 720); D1 (704 × 576/704
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 Kbps–6144 Kbps
H.265: 12 Kbps–6144 Kbps
Day/Night
Auto(ICR) / Color / B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto / natural / street lamp / outdoor / manual / regionalcustom
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detection
Off / On (4 Zone, Rectangle)
Region of Interest (Rol)
Yes (4 areas)
Smart IR
Yes
Image Rotation
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520resolution.)
Mirror
Yes
Privacy Masking
4 areas
Network
Network
RJ-45 (10/100Base-T)
Protocol
HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP;DHCP; DNS;
DDNS; PPPoE; IPv4/v6; QoS; UPnP; NTP; RTMP; Multicast; HTTPS; SFTP; 802.1x; ICMP; IGMP
Interoperability
ONVIF (Profile S/Profile G); CGI; Milestone; Genetec; P2P
User/Host
20
Edge Storage
Dahua Cloud; FTP; NAS
Browser
IEChromeFirefox
Management Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certification
CE (EN 60950:2000)
UL:UL60950-1
FCC:FCC Part 15 Subpart B
Power
Power Supply
12V DC/POE (802.3af)
Power Consumption
< 5.0W
Environment
Operating Conditions
-40°C to +55°C (-40°F to +131°F) /less than≤95%
Strorage Conditions
-40°C to +60°C (-40°F to +140°F)
Ingress Protection
IP67
